Easy-Core Chromatography Column
Easy-Core Chromatography Column
Introducton
Easy-Core™ is a manual low-pressure, borosilicate glass chromatography column, is an indispensable tool in the purification of proteins and other biomolecules. Their gentle operation, ease of use, cost-effectiveness, and versatility make them ideal for a wide range of applications, particularly in the biopharmaceutical industry. By understanding the features and benefits of these columns, researchers and technicians can optimize their purification processes and achieve high-quality results.
Features:
Less maintenance: Easy-Core™ columns required very less maintenance and no other electrical operations needed
Perfect fit for Lab-Scale to Pilot Scale: After optimization of purification processes using Lab-Core ™ columns, these columns is a perfect fit for pilot scale studies and generation of drug substance for clinical trials
Durable & Cost-Effective: Easy-Core™ are very robust and durable with affordable cost compared with automatic range of columns
No-Air Bubbles in bottom mesh: Liquid distribution plate ensures faster mobile phase draining from bottom plate, carrying all air bubbles with mobile phase
Easy-Core™ Columns:
LIQUID DISTRIBUTION PLATE
Easy-Core™ manual chromatography column is a redesigned new generation column, specifically studied over the years of experience for better mobile phase flow by placing liquid distribution plates and composite mesh structure which makes Easy-Core™ columns stand out in chromatographic operations with less back pressure readings compared with traditional manual chromatography columns.
This liquid distribution plate facilitates movement of buffer in & out from the column with ease resulting lesser back pressure i.e. at least drop of 0.5-0.85 bar of back pressure.
| Product Code | Model | Column Tube Material | Column tube inner diameter (mm) | Column Packing Height (mm) | Column Loading Volume (L) | Withstand Pressure (bar) | Overall Size(mm) | Maximum Height (mm) | Net Weight (KG) |
|---|---|---|---|---|---|---|---|---|---|
| ECC100BS500 | 100-500 | High Borosilicate Glass (Acrylic can be customized) | 102 | 0-400 | 0.3-2 | 5 | 540X480X1090 | 1600 | 25 |
| ECC100BS950 | 100-950 | 102 | 350-850 | 3-6.9 | 540X480X1540 | 2050 | 29 | ||
| ECC150BS500 | 150-500 | 152 | 0-400 | 0.7-2 | 550X500X1150 | 1650 | 34 | ||
| ECC150BS950 | 150-950 | 152 | 350-850 | 7-15.4 | 550X500X1600 | 2100 | 39 | ||
| ECC200BS500 | 200-500 | 197 | 0-400 | 0-12.2 | 510X510X1220 | 1700 | 46 | ||
| ECC200BS950 | 200-950 | 197 | 0-850 | 11-25.9 | 510X510X1670 | 2150 | 52 | ||
| ECC300BS500 | 300-500 | 296 | 0-400 | 0-27.5 | 5 | 570X570X1300 | 1780 | 98 | |
| ECC300BS950 | 300-950 | 296 | 350-850 | 26-58.5 | 570X570X1750 | 2230 | 109 | ||
| ECC450BS500 | 450-500 | 446 | 0-400 | 2.0-63 | 2.5 | 650X650X1090 | 1600 | 100 | |
| ECC450BS950 | 450-950 | 446 | 350-850 | 55.0-135 | 650X650X1540 | 2100 | 120 |
